How to Select Solar Submersible Pumps for Deep Wells Over 200 Meters: Multistage Design Guide
Introduction
Selecting a solar submersible pump for a 40 m well is routine; selecting one for a borehole beyond 200 m is a different engineering discipline. At that depth the margins that forgive imprecise sizing disappear: cable voltage drop becomes a dominant loss, stage count drives efficiency and shaft stability, and a mis-specified thrust bearing fails within a season. Deep boreholes are increasingly common as groundwater tables decline, and buyers using shallow-well habits often end up with pumps that cannot lift water to the surface at midday. Manufacturers such as KINBO build dedicated high-head multistage families for this reason.
Table of Contents
Why Deep Wells Change the Selection Rules
Total dynamic head above 200 metres pushes a solar pumping system into a regime where three effects compound.
Head dominates the power equation
Hydraulic power scales linearly with head. Delivering 5 m³/h against 220 m needs roughly five times the shaft power of the same flow against 45 m, multiplying array size, controller rating and cable cross-section. Small head errors thus carry a large capital penalty. Work through our method to calculate required head for a pump before shortlisting models.
Voltage drop becomes a first-order loss
A 220 m installation typically needs 240 to 260 m of cable once surface runs are included. At high current and modest conductor size, 6% to 10% of system voltage is lost in the cable, delaying start-up and shortening the pumping window.
Axial thrust and shaft dynamics tighten
Every added stage contributes axial thrust the bearing must absorb continuously. Deep-well pumps commonly run 20 to 40 stages, a thrust load an order of magnitude above a three-stage shallow pump, so bearing design and sand content dominate service life.
Field Data You Must Collect First
Nearly every deep-well failure traced to selection error begins with incomplete site data. Before requesting a quotation, collect:
- Static water level — after at least 12 hours of rest.
- Dynamic water level and drawdown — from a four-hour pumping test at the intended rate.
- Borehole yield — sustainable extraction rate in m³/h from the driller.
- Casing internal diameter and verticality — sets maximum pump diameter.
- Pump setting depth — normally 5 to 15 m below dynamic level, above the screen.
- Surface delivery profile — rise to tank, pipe length, diameter and fittings.
- Water analysis — sand content, TDS, chloride and iron.
- Solar resource — latitude and average peak sun hours.
Two items are omitted most often. Skipping the drawdown test lets actual dynamic head exceed design by 20 to 40 m, so the pump never reaches the tank; skipping the sand analysis means a standard bearing is supplied where a sand-resistant one was needed.
Multistage Configuration and Stage Count
A submersible pump generates head by stacking identical impeller and diffuser stages in series, each contributing a fixed head increment at a given flow. The design question is how to reach target head with acceptable efficiency, length and cost.
Fewer large stages or more small stages
Fewer high-head stages give a shorter, cheaper pump, but each stage runs closer to its mechanical limit. More low-head stages make a longer, slightly costlier pump with a flatter efficiency curve across the variable-speed range solar operation produces, which usually wins on daily water yield because a solar pump spends much of the day away from rated speed.
| Design Approach | Fewer High-Head Stages | More Low-Head Stages |
|---|---|---|
| Typical stage count at 220 m | 14 to 20 | 28 to 40 |
| Overall pump length | Shorter, easier handling | Longer, needs careful lowering |
| Efficiency at reduced speed | Falls off faster | Flatter, better daily yield |
| Axial thrust per stage | Higher | Lower and better distributed |
| Sand tolerance | Lower | Higher with floating stage design |
| Relative unit cost | Baseline | 8% to 15% higher |
Indicative comparison for 4-inch and 6-inch solar submersible pumps, 1.5 to 5.5 kW.
Material selection at depth
Above 200 m, stainless steel stage stacks are strongly preferred over plastic or cast components: higher internal pressure and continuous thrust load make dimensional stability essential, and the premium is small against well construction cost.
Motor Sizing and Voltage Selection
Deep-well solar pumps almost always use brushless DC or permanent magnet synchronous motors driven by an MPPT controller. Two sizing rules matter.
- Size on hydraulic power plus realistic efficiency — divide hydraulic power by combined pump and motor efficiency, typically 0.55 to 0.68 for high-head multistage units, then add 15% margin.
- Prefer higher system voltage — raising array voltage from 110 V to 220 V or 310 V cuts current proportionally, reducing cable losses quadratically.
Higher voltage also improves low-irradiance behaviour: a high-voltage string reaches the controller start threshold earlier, extending the daily pumping window by 30 to 60 minutes at no extra module cost.
Cable Design and Voltage Drop Control
Cable is the most frequently under-specified component in deep-well systems. Target no more than 3% voltage drop at rated current across the full run, including the surface section between array, controller and wellhead.
Practical guidance
- Calculate drop using full conductor length, not well depth alone.
- Use actual operating current at maximum power point, not nameplate current.
- Specify submersible-rated cable with water-blocking insulation; one poor joint at 220 m requires a full pull-out to repair.
- Where drop exceeds 3% at an affordable conductor size, revisit system voltage before adding copper.
A pull-out at this depth usually costs more than the pump itself, so premium cable and factory-terminated joints are justified. KINBO supplies matched cable and splice kits sized to the specific motor and depth so voltage drop is verified before shipment.
Deep Well Selection Matrix
| Total Dynamic Head | Target Flow | Indicative Motor Power | Suggested System Voltage |
|---|---|---|---|
| 200 to 230 m | 2 to 3 m³/h | 1.5 to 2.2 kW | 220 V DC |
| 200 to 230 m | 5 to 6 m³/h | 3.0 to 4.0 kW | 310 V DC |
| 250 to 300 m | 2 to 3 m³/h | 2.2 to 3.0 kW | 310 V DC |
| 250 to 300 m | 5 to 6 m³/h | 4.0 to 5.5 kW | 310 V DC or 380 V AC drive |
| Above 300 m | Any | Project-specific | Engineered solution required |
Indicative values at 5.5 peak sun hours, stainless steel multistage construction, cable drop below 3%. Confirm against certified pump curves for the specific model.
Frequently Asked Questions
Q: Can two pumps in series replace one deep-well pump?
A: Technically yes, and it is occasionally used for very high heads, but it doubles failure points inside the borehole and complicates control. For heads up to roughly 300 m a single correctly configured multistage unit is almost always the better choice.
Q: How much should I oversize the array for a 220 m installation?
A: Plan array capacity at 1.25 to 1.4 times motor rated power. High-head systems are more irradiance-sensitive because the pump delivers no water until it develops enough head to overcome static lift, so extra array capacity converts directly into a longer productive day.
Q: What sand content is acceptable at this depth?
A: Aim below 40 mg/L for standard configurations. Between 40 and 150 mg/L, specify sand-resistant stages and wear-resistant bearings. Above 150 mg/L the borehole should be redeveloped or screened before commissioning.
Q: Should the pump be set at the bottom of the borehole?
A: No. Setting it 5 to 15 m below the dynamic water level and above the screen section gives adequate submergence while avoiding the sediment layer at the base. Setting it deeper increases both head and sand ingestion for no hydraulic benefit.
Conclusion
Deep-well solar pumping succeeds or fails at the selection stage. Reliable field data, a stage configuration matched to variable-speed operation, a deliberately high system voltage and cable sized on total conductor length decide whether a 220 m installation delivers design flow for a decade or becomes a costly pull-out. Specifying a marginally more capable pump, better bearings and premium cable is nearly always the lowest-risk economic decision.
