Pump Curve Explained: How to Read, Interpret and Use a Solar Water Pump Performance Curve Correctly
Introduction
A pump curve is the map between flow, head and power for a given pump. Reading it correctly is how you confirm a solar pump will actually deliver your required water at your site’s head. KINBO publishes curves for every model so buyers can verify the operating point before ordering. This article explains what the curve shows and how to use it.
Table of Contents
The Curve’s Axes
Most curves plot flow rate (typically m3/h or L/min) on the horizontal axis and head in meters on the vertical axis, with additional lines for power and efficiency. A broader guide to choosing a solar water pump uses the curve as its foundation.
Reading a curve is simply finding where your duty point sits and checking the pump still performs there.
Every KINBO model ships with its curve so specifiers can validate before procurement.
Flow Versus Head
As head rises, flow falls – this is the pump’s fundamental trade-off. The curve shows the maximum flow at zero head and the shutoff head at zero flow.
| Head (m) | Flow (low) | Flow (high) |
|---|---|---|
| 10 | High | Higher |
| 40 | Medium | Medium |
| 70 | Low | Low |
If your required flow sits off the bottom of the curve, the pump is too small for the head.
Power and Efficiency
Power lines show wattage at each operating point; efficiency lines show where the pump wastes least energy. Aim for the operating point near peak efficiency to minimize panel count.
Efficiency matters most at large systems where extra panels are expensive.
Reading efficiency against the flow axis also helps when comparing two candidate pumps: the one with a wider high-efficiency band tolerates more variation in daily head as the tank fills or empties, protecting you from mild oversizing.
Finding the Operating Point
Take your required flow and calculated total head, mark them on the axes, and read the intersection. That point’s power line tells you the array size. KINBO curves make this a pencil-and-paper step.
Cross-check the power line against your panel budget before committing.
If the duty point falls in a low-efficiency zone, consider a different pump size rather than oversizing the array, since a better-matched pump often costs less over the project than extra panels and racking.
Common Mistakes to Avoid
Buyers often ignore friction loss, read only zero-head flow, or skip efficiency. All three cause under-performance. Always use total dynamic head, not just static lift.
Another frequent error is assuming nameplate flow applies at any head; the curve shows otherwise.
Frequently Asked Questions
What does a pump curve show?
It plots flow rate against head, with additional lines for power and efficiency, showing how a pump performs across operating conditions.
Why does flow drop as head rises?
A pump trades flow for lift; raising the head it must overcome reduces the volume it can move, which the curve captures.
How do I use the curve to size panels?
Find your flow and total-head operating point, then read the power line at that point to size the PV array with margin.
Where should I aim on the curve?
Near the pump’s peak efficiency band, which minimizes the array size and energy waste for your duty.
